Ziton ZP730-2P addressable optical smoke detector for compatible ZP7 fire-detection systems. Designed for early response to slow-burning and smouldering fires, it uses photoelectric light-scatter sensing with analogue alarm verification, automatic self-test and contamination compensation.
Key Features
- ZP7-series addressable optical smoke detector
- Designed for slow-burning and smouldering fire detection
- Photoelectric light-scatter sensing principle
- Analogue sensing with panel-based alarm verification
- Automatic self-test and contamination compensation
- 7-way DIP-switch addressing
- Red alarm LED indicator
- 2-core loop or spur wiring
- Compatible with ZP7 addressable systems
- EN54-7 compliant / CPR-certified design
- Polar White finish
Specifications
-
Brand: Ziton
-
Model: ZP730-2P
-
Detector Type: Addressable Optical Smoke Detector
-
Detection Principle: Photoelectric light scatter
-
Operating Voltage: 19.5–20.5V address line
-
Quiescent Current: Approx. 600µA
-
Alarm Current: Approx. 700µA
-
Coverage: Up to 100m² subject to local codes
-
IP Rating: IP32
-
Operating Temperature: -10°C to +75°C
-
Humidity: 20–95% RH, non-condensing
-
Dimensions: Approx. Ø106 × 52mm excluding base
-
Weight: Approx. 105g excluding base
-
Material: Moulded ABS
-
Colour: Polar White
Installation
The detector head plugs into a compatible Ziton ZP7 surface or semi-recessed detector base. Base selection and commissioning must match the installed ZP7 fire-alarm system.
What's in the Box
- 1 × Ziton ZP730-2P Addressable Optical Smoke Detector
Detector base is not included unless specifically supplied separately.
