WisNetworks Q800P 5GHz 802.11ac outdoor CPE with integrated 16dBi dual-polarised directional antenna. Designed for point-to-point and point-to-multipoint wireless links, it combines 2×2 MIMO, Gigabit Ethernet, passive PoE and an IP65 outdoor enclosure.
Key Features
- 5GHz Wi-Fi 5 / 802.11ac outdoor CPE
- Wireless speed up to 867Mbps
- 2×2 MIMO radio design
- Integrated 16dBi dual-polarised directional antenna
- Transmit power up to 26dBm
- 1 × Gigabit Ethernet port
- 24V passive PoE
- IP65 weather-resistant design
- Up to 8kV ESD protection
- Up to 4kV lightning protection
- WisOS support
- Auto-distance adjustment
- Designed for long-range PtP and PtMP links
Specifications
-
Brand: WisNetworks
-
Model: Q800P
-
Wireless Standards: 802.11a/n/ac
-
Frequency Range: 5.15–5.85GHz
-
Channel Width: 20 / 40 / 80MHz
-
Maximum Wireless Rate: 867Mbps
-
CPU: Qualcomm QCA9563 + QCA9886/QCN9886 platform
-
RAM: 64MB
-
Flash: 16MB
-
Antenna Gain: 16dBi dual-polarised directional
-
Beamwidth: Approx. 60° horizontal / 30° vertical
-
Ethernet: 1 × 10/100/1000 Base-T
-
Power: 24V DC, 0.5A passive PoE
-
Power Consumption: Under 10W
-
Dimensions: Approx. 260 × 100 × 60mm
-
Weight: Approx. 0.4kg
-
Operating Temperature: -40°C to +65°C
What's in the Box
- 1 × WisNetworks Q800P Outdoor CPE
- 1 × 24V Passive PoE Power Adapter
- 1 × Mounting Kit
- 1 × Quick Setup Guide
