Code-Hopping Receiver Module - 433.92MHz
Secure wireless receiver with advanced code-hopping encryption for enhanced security in access control and automation applications.
Technical Specifications
-
Transmission frequency: 433.92MHz
-
Modulation: ASK (Amplitude Shift Keying)
-
Protocol: Code hopping for enhanced security
-
Power source: 16V AC/DC or 200-250V AC 50-60Hz 1.5VA
-
Relay contacts: 5A @ 240V AC
-
Current consumption: 10mA idle, 40mA with relay active (at 13.8VDC)
-
Operating temperature: -30°C to +55°C
-
Dimensions: 90mm x 87mm x 31mm
-
Weight: Under 373g
