RUIJIE – 24 Port Gigabit PoE+ Switch
Power and performance built for professional CCTV and smart-network installations. The RUIJIE 24 Port Gigabit PoE+ Switch combines enterprise-level speed with intelligent cloud management, giving you the reliability and scalability needed for modern security and automation systems. Featuring 24 × Gigabit RJ-45 ports with PoE+ support and 4 × 10 Gb SFP+ uplinks, it’s designed to power cameras, access points, and IP devices efficiently — all managed through the Ruijie Reyee Cloud platform.
Why South African installers love it
-
Full Gigabit PoE+ performance: 24 × 10/100/1000 Mbps PoE+ ports (IEEE 802.3af/at) and 4 × 10 Gb SFP+ uplinks deliver seamless data and power for high-demand CCTV systems.
-
Cloud-managed simplicity: Configure, monitor, and manage remotely via the Reyee Cloud App or Web Portal — ideal for multi-site or off-grid setups.
-
Optimised for CCTV networks: IP-camera recognition, port isolation, broadcast storm control and auto-recovery keep your footage flowing and your network stable.
-
Enterprise-grade speed: Switching capacity up to 128 Gbps and forwarding rate around 95 Mpps ensure no bottlenecks during high traffic loads.
-
Reliable for local conditions: Surge protection up to 6 kV, operating range 0 °C to 50 °C, and 5-year warranty for peace of mind in South African climates.
Specifications & features
| Model |
RUIJIE 24 Port Gigabit PoE+ Switch (RG-NBS3200-24GT4XS-P) |
| Ports |
24 × 10/100/1000 Base-T PoE+ (RJ-45) + 4 × 10 Gb SFP+ uplinks |
| Switching capacity |
128 Gbps |
| Forwarding rate |
≈ 95 Mpps |
| PoE budget |
370 W total (IEEE 802.3af/at compliant) |
| MAC address table |
16,000 entries |
| VLANs supported |
Up to 4094 |
| Surge protection |
±6 kV (common & differential mode) |
| Operating temperature |
0 °C – 50 °C |
| Management |
Cloud-enabled via Reyee Cloud Platform and mobile app |
| Warranty |
5 Years |
Where it’s perfect
-
CCTV systems: Powers and connects up to 24 IP cameras for offices, homes or business parks with zero lag and high stability.
-
Smart buildings & automation: Ideal for networking access control systems, intercoms, and Wi-Fi access points with clean PoE+ distribution.
-
Commercial and industrial networks: Robust enough for data centres and enterprise applications needing fast uplinks and secure traffic segmentation.
Installation tips
- Install in a well-ventilated cabinet or rack with sufficient airflow and dust protection.
- Label each port clearly for zone tracking (“Front Cameras”, “Gate Access”, “Uplink”).
- Use surge protectors and a UPS to guard against power spikes or load-shedding interruptions.
- Update firmware via the Reyee Cloud App to access new features and enhanced security patches.
Frequently Asked Questions
Does this model support PoE+ for high-power devices?
Yes — the RUIJIE 24 Port Gigabit PoE+ Switch supports IEEE 802.3af and 802.3at standards, delivering up to 30 W per port for high-power devices like PTZ cameras and wireless access points.
Can I manage it remotely from my phone?
Yes — using the Reyee Cloud App or Web Portal, you can configure and monitor your switch remotely with zero-touch setup and real-time alerts.
Is this switch suitable for outdoor use?
No — this unit is intended for indoor installations such as server rooms, network racks, or secured cabinets. For outdoor use, install it in a weather-proof housing.
Boost your network’s power and reliability today. Add the RUIJIE 24 Port Gigabit PoE+ Switch to your setup and experience true enterprise-grade performance for CCTV, automation and smart connectivity in South Africa.
