RCT 1000/800W LONG RUN ONLINE TOWER UPS + 10A PSU
RCT 1000/800W LONG RUN ONLINE TOWER UPS + 10A PSU
Discover the incredible power and efficiency of Winner Pro! Designed for use in low power areas, this innovative UPS offers high power density and extended backup time while maintaining a compact size.
Perfect for critical business applications like ATMs and banking, it even allows users to customize the charging current for optimal performance. With a versatile range of output options, including pure sine waveform and adjustable frequency, this is a must-have for any business looking for reliable and efficient power solutions. Available now with an AC adapter output voltage of 230 and a wide input frequency range of 40-70.
FEATURES:
- True double- conversion online UPS
- Microprocessor control guarantees high reliability
- Wide input voltage range (110- 300 VAC)
- Input power factor correction 0.99
- Output power factor 0.8
- 50/60 Hz Frequency Converter Mode
- ECO mode operation for energy saving
- Smart SNMP works well with either USB or RS232 together
SPECIFICATIONS:
- Model : RCT- 1000- WPTU
- Phase : Single phase with ground
- Capacity : 1000 VA/800 W
Input
- Nominal Voltage : 100/110/115/120/127 VAC or 200/208/220/230/240 VAC
- Voltage Range : 55- 150 VAC or 110- 300 VAC @ 50% load | 85- 140 VAC or 160- 280 VAC@ 100% load
- Frequency Range : 40 Hz ~ 70 Hz
- Power Factor : ? 0.99 @ nominal voltage (100% load)
Output
- Output Voltage : 100/110/115/120/127 VAC or 200/208/220/230/240 VAC
- AC Voltage Regulation (Batt. Mode) : ± 1%
- Frequency Range (Synchronized Range) : 47~53 Hz or 57~63 Hz
- Frequency Range (Batt. Mode) : 50 Hz ± 0.25 Hz or 60Hz ± 0.3 Hz
- Current Crest Ratio : 3:1 (max.)
- Harmonic Distortion ?3 % THD (Linear Load) ; ? 6 % THD (Non- linear Load)
- Transfer Time : Inverter to Bypass - 4 ms (Typical)
Efficiency
- AC Mode : 88%
- Battery Mode : 83%
Battery
- Battery Type : 12 V / 9 Ah
- Numbers : 2
- Typical Recharge Time : 4 hours recover to 90% capacity
- Charging Current (max.) : 1 A
- Charging Voltage : 27.4 VDC ± 1%
Indicators
- LCD Display : UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions
Alarm
- Battery Mode : Sounding every 4 seconds
- Low Battery : Sounding every second
- Overload : Sounding twice every second
- Fault : Continuously sounding
RCT 1000/800W LONG RUN ONLINE TOWER UPS + 10A PSU
Discover the incredible power and efficiency of Winner Pro! Designed for use in low power areas, this innovative UPS offers high power density and extended backup time while maintaining a compact size.
Perfect for critical business applications like ATMs and banking, it even allows users to customize the charging current for optimal performance. With a versatile range of output options, including pure sine waveform and adjustable frequency, this is a must-have for any business looking for reliable and efficient power solutions. Available now with an AC adapter output voltage of 230 and a wide input frequency range of 40-70.
FEATURES:
- True double- conversion online UPS
- Microprocessor control guarantees high reliability
- Wide input voltage range (110- 300 VAC)
- Input power factor correction 0.99
- Output power factor 0.8
- 50/60 Hz Frequency Converter Mode
- ECO mode operation for energy saving
- Smart SNMP works well with either USB or RS232 together
SPECIFICATIONS:
- Model : RCT- 1000- WPTU
- Phase : Single phase with ground
- Capacity : 1000 VA/800 W
Input
- Nominal Voltage : 100/110/115/120/127 VAC or 200/208/220/230/240 VAC
- Voltage Range : 55- 150 VAC or 110- 300 VAC @ 50% load | 85- 140 VAC or 160- 280 VAC@ 100% load
- Frequency Range : 40 Hz ~ 70 Hz
- Power Factor : ? 0.99 @ nominal voltage (100% load)
Output
- Output Voltage : 100/110/115/120/127 VAC or 200/208/220/230/240 VAC
- AC Voltage Regulation (Batt. Mode) : ± 1%
- Frequency Range (Synchronized Range) : 47~53 Hz or 57~63 Hz
- Frequency Range (Batt. Mode) : 50 Hz ± 0.25 Hz or 60Hz ± 0.3 Hz
- Current Crest Ratio : 3:1 (max.)
- Harmonic Distortion ?3 % THD (Linear Load) ; ? 6 % THD (Non- linear Load)
- Transfer Time : Inverter to Bypass - 4 ms (Typical)
Efficiency
- AC Mode : 88%
- Battery Mode : 83%
Battery
- Battery Type : 12 V / 9 Ah
- Numbers : 2
- Typical Recharge Time : 4 hours recover to 90% capacity
- Charging Current (max.) : 1 A
- Charging Voltage : 27.4 VDC ± 1%
Indicators
- LCD Display : UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions
Alarm
- Battery Mode : Sounding every 4 seconds
- Low Battery : Sounding every second
- Overload : Sounding twice every second
- Fault : Continuously sounding
