HIKVISION HUMAN DETECTOR HM-TD1018-1/QR
Discrete Thermal Presence Detection for Smart Spaces
The HIKVISION HUMAN DETECTOR HM-TD1018-1/QR is a compact thermal presence sensor designed for privacy-friendly occupancy detection and automation. Using thermal sensing rather than conventional video, it reliably detects human presence, counts people and monitors temperature anomalies — ideal for offices, boardrooms, retail areas, clinics and smart buildings across South Africa.
Why this Detector Works for Your Site
-
Privacy-first occupancy sensing: Thermal detection provides accurate presence data without capturing recognisable images.
-
Accurate people counting: Supports presence and flow monitoring to help optimise space usage and staffing.
-
Temperature anomaly alerts: Built-in temperature monitoring can trigger alarm or automation rules for overheating or safety concerns.
-
Easy integration: Works with building automation, lighting and HVAC control systems via relay outputs and network interfaces.
-
Low profile design: Discrete, compact housing fits ceiling or wall mounts without altering the interior aesthetic.
Key Specifications
-
Model: HM-TD1018-1/QR
-
Thermal Resolution: 160 × 120 pixels
-
Pixel Pitch: 17 µm
-
Thermal Lens / Field of View: Wide-angle lens suitable for room coverage (mounting and placement affect exact coverage)
-
Sensitivity (NETD): Typically < 50 mK
-
Temperature Monitoring Range: –20 °C to +200 °C (configurable thresholds for alarms)
-
Power Supply: 5–16 V DC
-
Interfaces: Wi-Fi 2.4 GHz or wired network options depending on kit, micro-SD support for local events, relay output for automation
-
Mounting: Ceiling or wall mount; low-profile form factor
-
Operating Environment: Indoor use recommended; avoid direct sunlight or hot machinery in the immediate field of view
-
Dimensions / Weight: Compact and lightweight for easy mounting (refer to installation guide for exact dimensions)
Typical Applications
Perfect for meeting rooms, libraries, clinics, classrooms, retail fitting rooms and any interior space where privacy is important but occupancy or temperature monitoring is required. Useful for energy optimisation, automated lighting/HVAC control and discreet safety monitoring.
Installation & Commissioning Tips
- Mount the detector at ceiling height or high on a wall (typical indoor mounting: 2.5–3.5 m) for best coverage.
- Avoid aiming at direct heat sources (radiators, heaters, direct sun or hot plant equipment) which can distort readings.
- Adjust occupancy thresholds and temperature rules during commissioning to suit the room usage and typical heat signatures.
- Use the relay output to link presence detection directly to lighting or HVAC control for instant automation.
- Test detection zones after installation and tweak positioning for complete coverage with minimal false triggers.
Common Questions
-
Does this record video? No — it uses thermal sensing to detect presence and does not capture identifiable video.
-
Can it trigger building systems? Yes — relay outputs and network integration allow direct control of lights, HVAC and alarm systems.
-
Is it suitable for outdoor use? It is intended for indoor environments; outdoor installation is not recommended unless specified otherwise by your installer.
Smarter, Private Occupancy Detection
Bring privacy-aware intelligence to your building with the HIKVISION HUMAN DETECTOR HM-TD1018-1/QR. It delivers reliable occupancy data, useful temperature alerts and simple integration so you can automate and protect spaces without intrusive cameras. ✅ Available now at NeonSales.co.za
