HIKVISION DS-E08NI-Q1/8P — 8-Channel SSD NVR with 8-Port PoE
Overview
The DS-E08NI-Q1/8P is an 8-channel network video recorder with integrated 8-port PoE switch, designed for compact installations that demand IP recording with minimal cabling. Pre-configured with SSD storage options and efficient H.265+/H.265 compression, this NVR is ideal for small retail shops, offices, kiosks and branch sites in South Africa where simplicity and reliability matter.
Features & benefits
- Supports 8 IP camera inputs — enables full coverage for modest site sizes.
- Built-in 8 PoE ports (IEEE 802.3af/at) simplify installation and reduce external power wiring.
- Low power consumption (<10 W with SSD) and compact form factor (225 × 122 × 27 mm) make it suitable for constrained spaces.
- Efficient video compression (H.265+/H.265/H.264+/H.264) helps reduce storage and bandwidth requirements.
- Pre-installed SSD options (1 TB / 2 TB) provide fast boot and reliable recording with minimal maintenance.
Technical specifications
-
IP video inputs: 8-channels
-
Incoming bandwidth: 60 Mbps
-
Outgoing bandwidth: 60 Mbps
-
Decoding capability: Up to 4-channels @1080p (25 fps)
-
Video compression: H.265, Smart265, H.264, Smart264
-
PoE ports: 8 × RJ-45 10/100 Mbps, IEEE 802.3af/at, ≤58 W
-
Storage: SSD up to 2 TB pre-installed (model dependent)
-
USB ports: 2 × USB 2.0 (rear panel)
-
Network interface: 1 × RJ-45 10/100 Mbps
-
Power supply: 48 V DC, 1.36 A
-
Power consumption: ≤10 W (with SSD, without cameras)**
-
Working temperature: -10 °C to +50 °C
-
Dimensions: 225 × 122 × 27 mm; Weight ≤ 0.57 kg
Recommended applications
- Retail shops or boutiques needing IP video recording with minimal hardware.
- Branch offices or kiosks where camera power and cabling should be simplified.
- Small business sites upgrading from analogue DVRs to IP but with limited rack space.
Installation notes
- Ensure the total camera PoE budget does not exceed the NVR’s built-in port capability.
- Install in a ventilated area to maintain SSD and system longevity.
- Update firmware on commissioning, change default credentials and restrict network access to maintain security.
- Plan retention days based on resolution, motion events and SSD capacity.
