Overview
The Hikvision DS‑2DE2A404IW‑DE3/W(S6) is a compact 4MP Wi‑Fi mini PTZ that brings pan‑tilt coverage and 4× optical zoom to locations where running cable is difficult. It pairs a high‑resolution sensor with DarkFighter low‑light performance, built‑in IR and rugged weather/vandal protection — making it ideal for residential estates, shopfronts, parking bays and small commercial sites in South Africa.
What’s included
- DS‑2DE2A404IW‑DE3/W(S6) camera
- Quick start guide and warranty information
- Mounting template and fixings
Key features & benefits
-
4MP resolution — crisp 2560 × 1440 video for clear identification of faces and vehicles.
-
4× optical zoom (2.8–12 mm) — flexible coverage from wide view to useful zoom detail.
-
Wi‑Fi enabled — easy installation where Ethernet runs aren’t practical (2.4 GHz).
-
DarkFighter low‑light tech — improved detail in low ambient light.
-
Built‑in IR — up to ~20 m night range for reliable nocturnal monitoring.
-
Rugged & secure — IP66 weather rating and IK10 vandal resistance for exposed sites.
-
Efficient compression — H.265+/H.265 saves bandwidth and storage.
Technical specifications
-
Resolution: 4MP (2560 × 1440)
-
Lens / Zoom: 2.8–12 mm motorised (4× optical), 16× digital
-
Min. illumination: Colour 0.005 Lux @ F1.5 (AGC ON); B/W 0.001 Lux; 0 Lux with IR
-
IR range: Up to ~20 m (model dependent)
-
Pan / Tilt: Pan 0°–355°; Tilt 0°–90°; preset speed approx. 100°/s
-
Wi‑Fi: 2.4 GHz (IEEE 802.11 b/g/n)
-
Compression: H.265+/H.265/H.264+/H.264
-
Protection: IP66, IK10, lightning/transient protection
-
Mounting: Wall/ceiling/pole compatible with appropriate bracket
Recommended applications
- Residential driveways, entrance gates and estate monitoring
- Retail façades and small business perimeters
- Parking bays and guest drop‑off zones
- Sites where Wi‑Fi is preferred over Ethernet cabling
Installation & commissioning notes
- For Wi‑Fi installs ensure strong signal (RSSI ≥ −65 dBm) and secure network settings (WPA2, unique password).
- Mount between 2.5–6 m for balanced coverage and facial detail capture.
- Use presets and patrols to automate coverage of high‑priority areas.
- Enable firmware updates and secure management (HTTPS, change default credentials).
- Protect exposed cable entries with weatherproof junctions and sealants.
