| Camera |
|---|
| Image Sensor: |
� |
1/2.5" Progressive Scan CMOS |
| Signal System: |
� |
PAL/NTSC |
| Min. Illumination: |
� |
Color: 0.008 lux @(F1.2, AGC ON), 0.014 lux @(F1.6, AGC ON), 0 lux with IR |
| Shutter time: |
� |
1/3 s to 1/100,000 s |
| Slow shutter: |
� |
Support |
| Lens: |
� |
2.8 mm, horizontal FOV: 109�, vertical FOV: 60�, diagonal FOV: 131�
4 mm, horizontal FOV: 88�, vertical FOV: 46�, diagonal FOV: 105�
6 mm, horizontal FOV: 53�, vertical FOV: 30�, diagonal FOV: 61�
8 mm, horizontal FOV: 41�, vertical FOV: 23�, diagonal FOV: 48�
12 mm, horizontal FOV: 25�, vertical FOV: 14�, diagonal FOV: 29� |
| Lens Mount: |
� |
M12 |
| Adjustment Range: |
� |
Pan: 0� to 360�, tilt: 0� to 100�, rotate: 0� to 360� |
| Day& Night: |
� |
IR Cut Filter |
| Wide Dynamic Range: |
� |
120 dB |
| Digital noise reduction: |
� |
3D DNR |
| Focus: |
� |
Fixed |
| Compression Standard |
|---|
| Video Compression: |
� |
H.265+/H.265/H.264+/H.264/MJPEG |
| H.264 code profile: |
� |
Main Profile/High Profile |
| Video bit rate: |
� |
32Kbps~16Mbps |
| Triple Streams: |
� |
Yes |
| Image |
|---|
| Max. Image Resolution: |
� |
2688 � 1520 |
| Frame Rate: |
� |
50Hz: 25 fps (2688 � 1520, 2304 � 1296, 1920 � 1080)
60Hz: 30 fps (2688 � 1520, 2304 � 1296, 1920 � 1080) |
| Sub Stream: |
� |
50Hz: 25 fps (640 � 480, 640 � 360, 320 � 240)
60Hz: 30 fps (640 � 480, 640 � 360, 320 � 240) |
| Third Stream: |
� |
50Hz: 25 fps (1280 � 720, 640 � 360, 352 � 288)
60Hz: 30 fps (1280 � 720, 640 � 360, 352 � 240) |
| Image Enhancement: |
� |
BLC/3D DNR/ROI/HLC |
| Image Settings: |
� |
Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser |
| ROI: |
� |
Support 1 fixed region for main stream and sub stream separately |
| Day/Night Switch: |
� |
Day/Night/Auto/Schedule |
| Network |
|---|
| Network Storage: |
� |
microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Alarm Trigger: |
� |
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Protocols: |
� |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP,
IGMP, 802.1X, QoS, IPv6, Bonjour |
| General Function: |
� |
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy�
mask, Watermark, IP address filtering |
| System Compatibility: |
� |
ONVIF (Profile S, Profile G), ISAPI |
| Interface |
|---|
| Communication Interface: |
� |
1 RJ45 10M / 100M Ethernet interface |
| On-board storage: |
� |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Button: |
� |
Yes |
| Smart Feature-set |
|---|
| Behavior Analysis: |
� |
Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection |
| Line Crossing Detection: |
� |
Cross a pre-defined virtual line |
| Intrusion Detection: |
� |
Enter and loiter in a pre-defined virtual region |
| Unattended Baggage: |
� |
Objects left over in the pre-defined region such as the baggage, purse, dangerous materials |
| Object Removal: |
� |
Objects removed from the pre-defined region, such as the exhibits on display. |
| Exception Detections: |
� |
Scene change detection |
| Recognition: |
� |
Face Detection |
| General |
|---|
| Operating Conditions: |
� |
-30 �C ~ 60 �C (-22 �F ~ 140 �F)
Humidity 95% or less (non-condensing) |
| Power Supply: |
� |
12 VDC � 25%, PoE (802.3af Class3) |
| Power Consumption: |
� |
I5:
12 VDC, 0.7 A, max. 7.5 W
PoE (802.3af, 36V to 57V), 0.3 A to 0.1 A, max. 9.5 W
I8:
12 VDC, 1 A, max: 11.5 W
PoE (802.3af, 36V to 57V), 0.4 A to 0.2 A, max. 12.9 W |
| Weather Proof: |
� |
IP67 |
| IR Range: |
� |
-I5: up to 50 m; -I8: up to 80 m |
| Dimensions: |
� |
Camera: ?104.8 mm � 299.7 mm (?4.1" � 11.8")
Package: 386 mm � 156 mm � 155 mm (15.2" � 6.1" � 6.1") |
| Weight: |
� |
Camera: 1200 g (2.7 lb.) |
�
