General

• Operating Conditions: -30 �C ~ 60 �C (-22 �F ~ 140 �F) Humidity 95% or less (non-condensing)
• Power Supply: 12 VDC � 25%, PoE (802.3af Class3)
• Power Consumption: 12 VDC, 0.75A, max. 9.5W PoE (802.3af, 36V to 57V), 0.3A to 0.1A, max. 11W
• Impact Protection: IK10
• Weather Proof: IP66
• IR Range: Up to 30m
• Dimensions: ?153.4 � 133.1 mm (?6.04" � 5.24")
• Weight: Camera: 1287 g (2.84 lb.)

�

Camera

• Image Sensor: 1/2.8" Progressive Scan CMOS
• Signal System: PAL/NTSC
• Min. Illumination: Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR Color: 0.0068 Lux @ (F1.4, AGC ON), 0 Lux with IR
• Shutter time: 1/3 s to 1/100,000 s
• Slow shutter: Support
• Lens: 2.8 to 12 mm Horizontal field of view: 105�to 35� Vertical field of view: 56�to 20� Diagonal field of view: 126�to 40.5�
• Lens Mount: ?14
• Adjustment Range: Pan: 0� to 355�, tilt: 0� to 75�, rotate 0� to 355�
• Day& Night: IR Cut Filter
• Wide Dynamic Range: 120 dB
• Digital noise reduction: 3D DNR
• Focus: Auto

Compression Standard

• Video Compression: H.265+/H.265/H.264+/H.264/MJPEG
• Video bitrate: 32Kbps~16Mbps
• Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM
• Audio bitrate: 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
• Triple Streams: Yes

Image�

• Max. Image Resolution: 1920 x 1080
• Image Enhancement: BLC/3D DNR/BLC
• Image Settings: Rotate mode saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
• ROI: Support 1 fixed region for mainstream and sub-stream separately
• Day/Night Switch: Day/Night/Auto/Schedule/Triggered by Alarm In

Network

• Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
• General Function: One-key recovery, Anti-Flicker, three streams, heartbeat, mirror, password protection, video mask, Watermark, IP address filtering

• System Compatibility: ONVIF (Profile S, Profile G), ISAPI

Interface

• Audio: 1 input (line-in, 3.5 mm), 1 output (line out, 3.5 mm), mono sound
• Communication Interface: 1 RJ45 10M / 100M Ethernet interface
• Alarm: 1 input, 1 output (max. 12 VDC, 30 mA), terminal block
• Video Output: 1Vp-p Composite Output(75?) (For adjustment only)
• On-board storage: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
• Reset Button: Yes

�

Audio

• Environment Noise Filtering: Support
• Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHz

Smart Feature-set

• Behavior Analysis: Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection
• Line Crossing Detection: Cross a pre-defined virtual line
• Intrusion Detection: Enter and loiter in a pre-defined virtual region
• Unattended Baggage: Objects left over in the pre-defined region such as the baggage, purse, dangerous materials
• Object Removal: Objects removed from the pre-defined region, such as the exhibits on display
• Exception Detections: Scene change detection
• Recognition: Face Detection

�
