General
-
RS-485 Protocols: HIKVISION, Pelco-P, Pelco-D, self-adaptive
-
Language: English
-
Power Supply: 12V DC
-
Power Consumption: Max.18W
-
Working Temperature/Humidity: -30 �C-65�C(-22�F-149�F) 90% or less
-
Protection Level: IP66 standard (outdoor dome) TVS 4,000V lightning protection, surge protection and voltage transient protection
-
Mounting: Various mounting modes optional
-
Dimensions: ?164.5(mm)�295(mm)
-
Weight (approx.): 2Kg (4.41Ibs)
-
Mount Option: Long-arm wall mount: DS-1602ZJ; Corner mount: DS-1602ZJ-corner; Pole Mount: DS-1602ZJ-pole; Power box mount:DS-1602ZJ-box; Swan-neck mount: DS-1619ZJ
Camera Specifications
-
Image Sensor: 1/3" Progressive Scan CMOS
-
Effective Pixels: 1280(H)x720(V)
-
Signal System: PAL/NTSC
-
Minimum Illumination: Color: 0.05Lux@( F1.4,AGC ON); B/W: 0.005Lux@( F1.4,AGC ON), 0 Lux with IR
-
White Balance: Auto / Manual / ATW / Indoor / Outdoor
-
AGC: Auto/Manual
-
BLC: ON/OFF
-
WDR: DWDR
-
Shutter Time: 1-1/10,000s
-
Day& Night: ICR
-
Privacy Mask: 8 programmable privacy masks
-
Auto Focus: Auto / Semi-automatic / Manual
Lens
-
Focal Length: 4-92.0mm, 23x
-
Zoom Speed: Approx.3s(Optical Wide~Tele)
-
Field of View: 49-2.2 degree(Wide-Tele)
-
Minimum Working Distance: 10~1,000mm(Wide~Tele)
-
Aperture Range: F1.4-F3.5
Infrared
-
IR Distance: 100m
-
IR irradiation angle: Adjustable by zoom
�
�
