Video/Audio Input:
Two-way audio input: 1-ch, RCA (2.0 Vp-p, 1k?)
IP video input: 16-ch

Network:
Remote connection: 128
Incoming bandwidth: 160Mbps
Outgoing bandwidth: 256Mbps

Video/Audio Output:
HDMI Output: 1-ch, resolution: 4K (3840*2160)/60Hz, 4K (3840*2160)/30Hz, 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz
Recording Resolution: 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Audio Output: 1-ch, RCA (Linear, 1k?)
Synchronous Playback: 16-ch
VGA Output: 1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz

Decoding:
Capability: 4-ch@8MP,16-ch@1080P
Live view / Playback: 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Hard Disk:
SATA: 4 SATA interfaces for 4HDDs
Capacity: Up to 6TB capacity for each HDD

External Interface:
Network Interface: 1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface
Serial Interface: RS-232; RS-485;
USB Interface: Front panel: 2 � USB 2.0�
Rear panel: 1 � USB 3.0
Alarm In: 16-ch
Alarm Out: 4-ch

POE:
Supported Standard: AF and AT
Interface: 16 independent 10/100 Mbps PoE Ethernet interfaces
Max. Power: 200W

General:
Power Supply: 100 to 240 VAC
Consumption (without hard disk and POE): ?20 W
Working Temperature: -10 oC ~ +55 oC (+14 oF~ + 131 oF)
Working Humidity: 10 % ~ 90 %
Chassis: 19-inch rack-mounted 1.5U chassis
Dimensions: 445 � 390 � 70 mm (17.5"� 15.3" � 2.8")
Weight (without HDD): ? 5 Kg (11 lb)

�

INCLUDES: 2 YEAR WARRANTY�
