An extensive range of scopes to suit all calibres and disciplines.
All Vantage riflescopes feature our H2 optics in a variety of configurations.
- Capped Low-Profile Turrets
- 1 Inch Mono-Tube Chassis
- Adjustable Objective For Parallax Correction
- 11 Layer Fully Multi-Coated Lenses
- High Torque Zoom Ring
- Fast Focus Eyebell
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Hawke Warranty.
Mil Dot Reticle
The classic Mil Dot features multiple aim points for hold-over and hold-under. Accurate mil spacing on 10x, featuring 4 Mil Dots in each direction.
Technical Specifications;
|
Objective Lens |
32mm |
|
Reticle |
Mil Dot |
|
Parallax |
Adjustable Objective |
|
Magnification |
4x |
|
Optical System |
System H2 |
|
Focal Plane |
SFP (Second Focal Plane) |
|
Scope Tube |
1 Inch |
|
Illumination |
N/A |
|
Field of View |
28.5ft @100yds |
|
Field of View |
5.4° |
|
Eye Relief |
3.5in |
|
PX/Focus |
5yds - ∞ |
|
Exit Pupil |
0.31″ |
|
Weight |
13.1oz |
|
Length |
11.9″ |
|
Turret Type |
Capped |
|
Turret Caps |
YES |
|
Click Value |
1⁄ 4MOA |
|
Elevation Turret Clicks (max) |
165 MOA |
|
Windage Turret Clicks (max) |
165 MOA |
|
Ocular Type |
Fast Focus |
|
Power Selector |
Knurled Posi-Grip |
|
Lens Coating |
Fully Multi-Coated - 11 Layers |
Download
The product instructional manual can be downloaded here
