�Key Features:

AMX IR Duplex Reticle, SFP
Partially Illuminated, Red
Wide Angle for Varmint/Airgun Use
30mm One-Piece Maintube
Integrated adjustable objective for parallax adjustment
1/10 MRAD capped, resettable target turrets
Fast focus eyebell and high torque zoom ring
Threaded objective/ocular for optional accessories

Waterproof, Shockproof, Nitrogen purged (to nullify any chance of interior misting, due to condensation) and shockproof

AMX reticle:

The AMX reticle is based on the spacing of a 10x Mil Dot. the AMX offers multiple aim points, useful when shooting air guns with loopy trajectories.

Length: 329mm / 13"�(which is compact for a 6-24x50)

Weight: 670g

Eye relief: 76mm / 3"

Focus/Parallax - Side Focus: 9m - ?

Field of View: 7.3 - 1.8m @100m

Exit Pupil: 8.3 - 2.1mm / 0.33-0.08"

Chassis: 30mm Mono-tube

Magnification Range: 6-24x optical zoom

Objective: 50mm -�fully 16 layer multi coated lenses for optimal clarity / visual report. Since these aren't inlaid wires, they will therefore not come loose due to airgun recoil and appear collapsed as is the case when using heavy recoiling break barrel rifles.

Reticle Illumination: Red only -�

Reticle: AMX IR�- laser etched onto the glass, not standard wire crosshairs, so it won't fade over time.

Elevation Increment: 1?10 MRAD

Elevation Adjustment Range: 16 MRAD

Windage Increment: 1?10 MRAD

Windage Adjustment Range: 16 MRAD

Material: Aluminium

Ocular Type: Fast Focus

Power Selector Style: Knurled Posi-Grip

Focal Plane: Second Focal Plane (SFP)

Turret Caps: Yes, Aluminium

Turret Type: Capped Target Turrets
