ET TOONA7 SWING GATE MOTOR KIT - SINGLE
Catering to industrial swing gates with a maximum of 7m for each gate, the ET Toona7 Swing Gate Motor Kit - Single is an automatic gate opener specifically designed for heavy-duty singular swing gates. It can handle gates up to 7 meters in length and with a weight of up to 1700 kilograms (for gates less than 3 meters).
FEATURES:
- POWERFUL operator for swing gate leaves up to 7m
- ROBUST cast aluminium design with powder coating
- Proven POWER PACK operation with true battery backup
- LED DISPLAY for easy programming and diagnostics
- Magnetic encoder ensures reliable and precise obstacle detection
- Easy installation, operation and maintenance
- ET-Blu Mix® enhanced rolling code receiver on-board
SPECS:
Input voltage: (Standard kit option)
|
230v AC, 50Hz-60Hz
|
Primary supply to the electric motor
|
ACDC Power Pack with battery as back-up only (24V, 3.5Ah
|
Maximum duty cycle (work rate) with mains present
|
30 Cycles/hour
|
Number of operations on battery reserve without AC mains present
|
30 within the fi rst 24h of power failure
|
Maximum gate mass
|
200kg (<1.5m leaf)
|
Maximum gate leaf length
|
3m (<100kg mass)
|
Rated force
|
1500N
|
Rated linear running speed: †
|
40mm/sec
|
Typical operating time through 90˚*
|
<10 seconds
|
Built-in receiver
|
434MHz, 4 channel, ET BLU MIX® Enhanced rolling code. 999 user standard capacity (SMXI)
|
