Energy [J (Ft/lbs)]: 250 (9.85) Barrel (Energy is adapted to your country legislation) |
Min: 7,5J - Max: 43J 5,5 ft·lbs - 31,7 ft·lbs |
Energy: 600mm (23.60") Barrel (Energy is adapted to your country legislation) |
Min: 7,5J - Max: 77J 5,5 ft·lbs - 56,8 ft·lbs |
Regulator pressure (adjustable) |
By default from factory: 130 BAR. Can be easily adjusted between 60 BAR and 240 BAR |
Standard Plenum Volume |
42 cm3 |
Air Volume from Factory |
137 cm3 + 42 cm3 (standard plenum) = 179 cm3 |
Air Volume with 350cc bottle |
395 cm3 (137 cm3 - 92 cm3 + 350 cm3) + 42 cm3 = 437 cm3 |
Max Filling Pressure |
300 BAR |
Magazine Capacity |
8 |
Ready for Pellets and Slugs |
Yes. Magazines can be loaded with pellets or slugs with a maximum length of 11mm |
Weight with 250mm Barrel |
2,10 Kg - 2,30 Kg |
Weight with 350mm Barrel |
2,30 Kg - 2,50 Kg |
Weight with 450mm Barrel |
2,60 Kg - 2,80 Kg |
Weight with 600mm Barrel |
3,10 Kg - 3,30 Kg |
Total Length with 250mm Barrel and standard BUTT |
656mm with OEM suppressor / 720mm with Shelest, Shopot, Shorokh and Tishina 150 / 770mm with Tishina 200 |
Total Length with 350mm Barrel and standard BUTT
|
756mm OEM suppressor / 820mm with Shelest, Shopot, Shorokh and Tishina 150 / 870mm with Tishina 200
|
Total Length with 450mm Barrel and standard BUTT
|
920mm with Shelest, Shopot, Shorokh and Tishina 150 / 970mm with Tishina 200
|
Total Length with 600mm Barrel and standard BUTT
|
1070mm with Shelest, Shopot, Shorokh and Tishina 150 / 1120mm with Tishina 200
|
Length folded |
- 299 mm (to know this, you should rest 299 to Total Length) |
Max Height |
164mm |
Max Width |
45mm |
Max Width folded |
76mm |
Barrel Manufacturer |
Lothar Walther / Alfa Precision
|
Barrel TWIST · Lothar Walther |
Twist: 16.1" (410mm) |
Barrel TWIST · Alfa Precision |
Twist: 16" (406mm)
|
Barrel Length |
250mm (9,85") / 350mm (13,75") / 450mm (17,70") / 600MM (23,60") |
Barrel Thread |
M14x1,25 |
Barrel External Ø |
14mm |
Barrel # Grooves · Lothar Walther |
12 |
Barrel # Grooves · Alfa Presicion |
6 (polygonal) |
Land Ø · Lothar Walther |
5,47 ±0,01 |
Land Ø · Alfa Precision |
5,43 (±0,01)
|
Groove Ø · Lothar Walther |
5,63 (±0,01) |
Groove Ø · Alfa Precision |
5,61 (±0,01)
|
Barrel Choke · Lothar Walther |
Yes: 0,01 mm (±0,005)
|
Barrel Choke · Alfa Precision |
No choke |
Barrel Crown Angle · Lothar Walther / Alfa Precision |
30º |
Grip |
EDgun grip with a standard AR15 crib. Any AR15 grip without tail fits perfectly well. |
Charging Connector Type |
EDgun fill-probe (included with the gun) |
