PFM344D-8CH-EN – Switching Power Supply (8-Channel Power Supply) in South Africa
The PFM344D-8CH-EN Switching Power Supply is a reliable and efficient multi-channel power solution designed to supply power to multiple devices simultaneously. With 8 output channels and adjustable voltage levels, this power supply offers flexible compatibility for security systems and surveillance equipment.
Built with protection against overcurrent, overvoltage, and short circuits, the PFM344D-8CH-EN ensures stable and safe operation for connected devices. Its wall-mount installation design allows easy setup and space-saving installation, making it an ideal choice for CCTV and security applications.
Why Choose the PFM344D-8CH-EN Switching Power Supply?
-
8 Output Channels – Power multiple devices at the same time
-
Adjustable Output Voltage – Three levels (12V, 13.5V, 15V) for device compatibility
-
Overcurrent & Short-Circuit Protection – Enhanced safety and reliability
-
Surge Protection – Common mode: ±4 kV | Differential mode: ±2 kV
-
V-0 Fireproof Rating – Improved safety and durability
-
Wall Mount Installation – Space-efficient and easy setup
-
High Efficiency – ≥88% efficiency for stable power delivery
-
CE Certified – Compliance with international safety standards
Function & Performance
-
Input Voltage: 100 VAC – 240 VAC
-
Output Voltage Options:
-
Normal: 12 VDC
-
Long: 13.5 VDC
-
Ex-Long: 15 VDC
-
-
Rated Output Current:
-
Normal: 5A
-
Long: 4.5A
-
Ex-Long: 4A
-
-
Rated Power: 60W total (12W per channel)
-
Idle Power Consumption: ≤0.21W
-
Efficiency: ≥88%
Protection Features
-
Overcurrent Protection
-
Overvoltage Protection
-
Short-Circuit Protection
-
Surge Protection:
-
Common Mode: ±4 kV
-
Differential Mode: ±2 kV
-
-
Static Protection:
-
Air Discharge: ±8 kV
-
Contact Discharge: ±6 kV
-
Ports & Connectivity
-
Input Port: 2-core female C8 socket (European standard cable)
-
Output: 8-channel terminal output
Structure & Installation
-
Installation Type: Wall mount
-
Dimensions: 140.1 × 94.5 × 34.2 mm
-
Net Weight: 0.27 kg
-
Gross Weight: 0.35 kg
-
Color: Gray
-
Input Cable Length: 1000 mm
Environmental Specifications
-
Operating Temperature: 0°C to +40°C
-
Storage Temperature: -40°C to +80°C
-
Operating Humidity: 10% – 90%
-
Storage Humidity: 5% – 95%
Certifications
-
CE Certified
Perfect for South African Security Installations
The PFM344D-8CH-EN Switching Power Supply is an excellent choice for CCTV systems and multi-device security setups. Its stable power distribution, safety features, and adjustable voltage output make it a dependable solution for professional installations.
Order your PFM344D-8CH-EN Switching Power Supply today and ensure efficient and stable power delivery for your security system — fast delivery available across South Africa.
