AJAX COMBI PROTECT - WHITE
Combi Protect Jeweller
Wireless combined motion and glass break detector. The device helps to secure the room from intruders entering through doors and windows, and monitors the current state of the glass.
Operates up to 5 years without battery replacement
Ignores cats and dogs with weight of up to 20 kg and height up to 50 cm
Detects motion at a distance of up to 12 m and breakage at up to 9 m
Principle of operation
The device combines the functions of two detectors — motion detector and glass break detector. It detects motion in the room at a distance of up to 12 m and registers broken glass at a distance of up to 9 m from the window.
Features
The device detects motion even in hot climates by means of temperature compensation. It filters false alarms caused by thunder, dogs barking or the sound of passing trucks.
Installation and set up
Ready to operate straight out the box: the battery is already installed, therefore there is no need to disassemble the detector. With one click, it can be connected to the hub in the mobile application. It can be mounted on the SmartBracket in just a few minutes.
SPECS:
Compliance
EN 50131-2-2 (Grade 2)
PD 6662:2017
UL369
Compatibility
Hubs
Hub, Hub Plus, Hub 2 (2G),
Hub 2 (4G), Hub 2 Plus,
Hub Hybrid (2G), Hub Hybrid (4G)
Range extenders
ReX, ReX 2
Communication
with control panel
Jeweller communication
technology
Frequency bands
866.0–866.5 MHz
868.0–868.6 MHz
868.7–869.2 MHz
905.0–926.5 MHz
915.85–926.5 MHz
921.0–922.0 MHz
Jeweller communication range
up to 1,200 m
Depends on the region of sales.
In an open space.
Motion detection
Sensitive element
1 × PIR sensor
Detection distance
up to 12 m
Motion detection angle
horizontal — 88.5°
Pet immunity
weight: up to 20 kg
height: up to 50 cm
Glass break detection
Sensitive element
1 × electret microphone
Detection distance
up to 9 m
Horizontal glass break detection
angle
180
Power supply
Battery
1 × CR123A
Battery life
up to 5 years
Pre-installed.
Installation
Operating temperature range
from –10°С to +40°С
Operating humidity
up to 75%
Protection class
IP50
Enclosure
Colour
white, black
Dimensions
110 × 65 × 50 mm
Weight
92 g
Complete set
Combi Protect Jeweller
1 CR123A battery
Smart Bracket mounting panel
Installation kit
Quick start guide
