DAHUA
SKU:10416
Couldn't load pickup availability
Recently viewed products
WE DELIVER ANYWHERE
2 - 3 WORKING DAY NATIONWIDE DELIVERY
GREAT PRICES
FOUND IT CHEAPER? LET US KNOW
FIVE STAR SERVICE
OUR SUPPORT TEAM IS ONLY A CLICK AWAY
FLEXIBLE PAYMENT OPTIONS
MULTIPLE PAYMENT OPTIONS
System
Main Processor
32 Bit
Input/Output Ports
Input
Door sensor x 1, Exit button x 1
Output
Relay x 1 (Door lock,)
Reader
Reader x 1
Card Read
Read Format
13.56MHz
125KHz
Read Range
1cm–2cm (max.)
Response Time
<0.1s
Capacity
Cardholders
30,000
Events
60,000
Function
User Management
General, VIP, Guest, Patrol, Block list, Duress
Alarm Function
Door time out alarm, Intrusion alarm, Duress alarm, Tamper alarm
Period Setting
Support 128 groups of schedule, 128 groups of periods and 128 groups of holiday periods
Interface
To PC
RJ45(10/100M)
To Reader
Wiegand26/34, RS485
General
Ingress Protection
IP66 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.)
RTC
Yes
Beep Tone
Buzzer
Keyboard
Sensitive touch keypad with blue backlight
Power Supply
DC 9-15V/100mA
Operating Temperature
-30°C to +55°C
Working Humidity
10%RH–90%RH (no-condensation)
Dimension(W×D×H)
62.0mm×142.0mm×23.0mm
Weight
0.5kg
Working Environment
Outdoor
Certificates
CE
FCC
